| Fe memory:
|
Supported •Stores the flash output of E-TTL II / E-TTL autoflash and automatically sets the stored output level if users switch the flash mode to manual flash. *Flash output may vary slightly between E-TTL autoflash and manual flash. •Colors may vary between E-TTL autoflash and manual flash under the following conditions: *When the color temperature of the Speedlite light differs greatly from that of ambient lighting and flash exposure compensation is set toward the negative end. *When E-TTL balance is set to [Ambience priority]. •Differences in colors between E-TTL autoflash and manual flash may be reduced by taking one of the follow steps: *Using the provided color filter. *Setting white balance to an option other than AWB. *When combined with specific cameras, FE Memory is possible by operating the camera buttons (by using the camera’s C.Fn of by custom buttons). |
| In the box:
|
Speedlite EL-10; Soft case; Stand |
| Personal functions:
|
Function Number Setting P.Fn-01: LCD Panel Contrast Display contrast: 5 levels P.Fn-02: QUICK (Quick Flash) 0 On (enabled) 1 OFF (disabled) P.Fn-03: LINKED SHOT (FLASH FIRING DURING LINKED SHOOTING) 0 OFF (disabled) 1 On (enabled) P.Fn-04: DIRECT (Change settings with dial) 0 OFF (disabled) 1 On (enabled) |
| Modeling lamp:
|
Not available |
| Techs specs detailed pdf:
|
View Full Details of Technical Specification |
| Receiver functionality:
|
Sender unit functions that receivers can control remotely •Remote release •Test flash •Modeling flash Footnote*1 *Sub-senders cannot be controlled remotely *1. Modeling flash is only available by using the combination of a camera, not from the EOS R series or the EOS M series, with a compatible Speedlite as a sender, and using EL-10 as a receiver. |
| Communication functions:
|
Compliance standards IEEE 802.15.4, ARIB STD-T 66 Communication method Primary modulation: OQPAK Secondary modulation: DS-SS Transmission frequency 2405-2475 MHz Channel Channel 1-15 Setting: Auto / Manual Wireless Radio ID 0000 to 9999 Setting: Manual Transmission range** Approx. 98.4 ft. / 30 m Groups Up to 5 groups (A-E) *Sender units are set to Group A Number of possible units for communication Up to 16 units of senders and receivers in total Max. sender units Up to 15 *Secondary and additional units serve as sub-senders Max. receiver units Up to 15 *1: Without any obstructions between senders and receivers, and without radio interference from other devices. *2: Transmission range may be shorter depending on factors such as how units are arranged, the surrounding environment, and weather conditions. |
| Transmission status display:
|
Lamp LCD Panel Sender Receiver Connected Yes Yes On (in green) Sender, Receiver Not Connected Yes Yes Off Sender, Receiver Too many units/Error Yes Off Sender, Receiver Sub-sender Yes On (in green) Sub Sender *1: Without any obstructions between senders and receivers, and without radio interference from other devices. *2: Transmission range may be shorter depending on factors such as how units are arranged, the surrounding environment, and weather conditions. |
| Recharge level:
|
Normal Flash State when fully charged and the Speedlite can be used without restriction Quick Flash Can fire, but some restrictions apply: * Max. intensity is in a range of approx. 1/2 to 1/3 of the fully charged intensity. *No Quick flash firing under the following conditions: • When P.Fn-01: Quick flash is set to OFF. • When using a camera that does not support E-TTL II/E-TTL autoflash. • When used wirelessly via radio transmission. • When the manual flash output is set in the range of 1/1 to 1/3.2 Charging in progress Does not fire in this state. |
| Wireless functions via optical transmission:
|
Not supported |
| Compatible cameras:
|
EOS cameras equipped with a Multi-function Shoe |
| Feb:
|
±3 stops, in 1/3-stop or 1/2-stop* increments. *FEB is automatically deactivated after three shots. *Can be used with flash exposure compensation and FE lock. *1: Corresponds to exposure level increments on the camera. |
| Light distribution:
|
Set in C.Fn-21 0: Standard A light distribution setting that balances light distribution and the guide number. 1: Guide number priority Prioritizes illumination at the center of the screen, the periphery may be dark. 2: Light distribution priority Light distribution that reduces peripheral darkness. |
| Wireless functions via radio transmission:
|
The Speedlite EL-10 can be set to function as a sender or receiver in wireless flash photography using radio transmission Second-curtain sync The Speedlite EL-10 supports second-curtain synchronization in radio transmission wireless shooting. |
| Power source:
|
Battery Pack - 4 x AA/LR 6 alkaline batteries *AA/HR 6 Ni-MH batteries can be used, AA/FR 6 lithium batteries cannot be used. |
| External power source:
|
Not Supported |
| Recharge time:
|
Battery Quick Flash Normal Flash AA/Alkaline 0.1–2.2 sec. 0.1–2.5 sec. AA/Ni-MH 0.1–1.3 sec. 0.1–1.5 sec. |
| Dot count:
|
Approx. 12,000 dots (172 x 72) |
| Wireless firing control:
|
via radio transmission Flash Mode E-TTL II / E-TTL autoflash Manual flash Stroboscopic flash Group firing E-TTL II / E-TTL autoflash Manual flash Auto external flash metering |
| Radio transmission wireless shooting time:
|
Approx. 9 hrs. continuously *Time until the Speedlite turns off with sender flash firing disabled, when using radio transmission wireless * Using new AA/LR 6 Alkaline batteries, based on Canon testing standards. |
