Blackmagic Design ATEM 1 M/E Constellation HD

The Blackmagic Design ATEM 1 M/E Constellation HD is a live production switcher with 10 standards-converted 3G-SDI inputs, each carrying its own full up/cross converter, so you can mix video standards freely across the board without a separate converter for each source. It includes 6 x 3G-SDI outputs, DVE, 4 ATEM Advanced chroma keyers, a 16-way multiview, media players, built-in talkback, and USB webcam output, all controllable from the free ATEM Software Control or an optional ATEM Advanced Panel.

• 10 Standards-Converted 3G-SDI Inputs: each input has its own dedicated converter, so any 1080p source works regardless of its native standard.
• 4 ATEM Advanced Chroma Keyers: with a color picker for automatic key parameter generation, edge/flare controls, and a foreground color corrector for matching foreground to background.
• 16-Way Multiview: fully customizable to 4, 7, 10, 13, or 16 simultaneous views with tally borders, source labels, and VU meters.
• Built-In Fairlight Audio Mixer: 6-band parametric EQ, compressor, limiter, and expander on every SDI input.
• USB Webcam Output: the switcher appears as a standard webcam to Zoom, Teams, or any streaming software over USB-C.
• Program/Preview Switching: true broadcast-style program/preview operation, matching the workflow used by professional broadcasters, with a compact rack-mount design and built-in control panel.
