Blackmagic Design Videohub Mini 4x2 12G

The Blackmagic Videohub Mini 4x2 12G is a compact zero-latency video router that lets you route any combination of SD, HD, and Ultra HD sources at once, aimed at productions that need extra input switching for ATEM switchers, HyperDecks, or monitors without a full-size router taking up rack space. Front-panel buttons make routing as simple as pressing a destination then a source, while an emergency 12G-SDI patch connection on the front panel means unexpected gear can be added on the fly without rewiring the rack. Because clean switch is set per output rather than per input, a HyperDeck can stay on a direct feed while a monitor output uses clean switching at the same time.

• 4x2 12G-SDI routing in 1/3 rack width: Routes any combination of SD, HD, and Ultra HD up to 2160p60 simultaneously.
• Front-panel emergency patch and webcam output: Includes a 12G-SDI patch connection for unplanned gear plus a USB-C webcam output for streaming or conferencing software.
• Per-output clean switch: Each output independently chooses clean or direct switching, so a recorder can avoid inserted frames while a monitor gets seamless transitions.
• Built-in SDI re-clocking: Regenerates every input signal to prevent dropouts on long cable runs.
• Dual power redundancy: Built-in AC power supply plus a 12V DC connection keeps the router running through a PSU fault.
• Free software and hardware control options: Controlled via free Mac/Windows/iPad software or optional Master Control Pro and Smart Control Pro hardware panels.
