VigilLink AVoIP controller for JP4K3K and JP4K6K

VigilLink AVoIP controller for JP4K3K and JP4K6K
VigilLink??s Video over IP Controller is used to control and manage JPEG2000 IP products. It supports dual 100M network ports, which can realize dual-network isolation of Control network and Multicast video distribution network. Built-in Web GUI, TCP and RS-232 control are supported. It supports POE function and wide-band 12V IR signal receiving. Since the demand of IP products is daily increased in the current market, the IP Controller will be widely applied in more and more different scenarios.
Featured Highlights?

Easy to create project, control and manage the system
Flexibly support Auto, DHCP and Manual three types of IP configurations
HTTPS, SSH, SFTP security compatible
Built-in Web GUI control interface, supporting Drag & Drop operations
Support image preview
Support video, audio, RS-232, IR, KVM, CEC control and management of the distributed system
Dual network ports (VIDEO LAN port supports POE function) to isolate Controls and Multicast networks
Support LAN/RS-232 port control and third-party central control
Support IR signal receiving (3.5mm audio jack, 12V level)
4 channel GPIO control ports (5V/12V optional level)
Multiple circuits protection, lightning protection and ESD design
Reliable system design, ensuring 24/7 stable usage

Package Contents
1?? Video over IP Controller
1?? 20kHz-60kHz 12V IR Receiver Cable (1.5 meters)
1?? 3-pin 3.81mm Phoenix Connector (Male)
1?? 6-pin 3.81mm Phoenix Connector (Male)
2?? Mounting Ears
4?? Machine Screws (KM3*4)
1?? 12V/1A Locking Power Adaptor
1?? User Manual
