VigilLink M811 Lite (M811L) Warping Box

VigilLink M811 Lite (M811L) Warping Box
Introducing M811L, the versatile warping box with advanced technology designed for seamless projector displays. With 4 input ports (2x HDMI, 1x DP, 1x VGA) and 1x HDMI output port, M811L supports digital input of up to 7680x2160 @30Hz and 5760x1200 @60Hz with 4:4:4 full-color sampling. Its 10-bit high-end processor, motion adaptive de-interlace, low angle smooth algorithm, and 3:2/2:2 pull-down capabilities ensure optimal video results.
With advanced warp technology, M811L allows users to use an IR controller, USB, Web Page, and Ethernet to perform edge blending and sophisticated geometry alignment with up to 120x68 control points. New features include Linearity Grid Line Adjustment for compete for line movement up to 17x9 control points and "W" type Corner Wall image adjustment. The video wall function allows easy to split and allocate the source image, while the overlap function allows for cropping, shifting image position, and changing aspect ratio.
M811L also features an HDMI loop for signal source monitoring, multi-unit daisy chain connection, and standard functions such as PIP (picture in picture) and POP (Picture outside Picture). The PIP image size can be adjusted from 320x180 to 1920x1200 with flexible position and aspect ratio adjustment. At the same time, the overlap function allows different image sizes, aspect ratios, and cropping area adjustment in the PIP window.
Whether for image stacking, geometry alignment, PIP, POP, image format conversion, de-interlacing, image rotation, or mobile mirror image displayed on portrait TV, M811L provides an easy-to-use, cost-effective, reliable, and flexible solution.
Featured Highlights

Modularized design of edge blending processor
Up to 120??68 warp control point
Embedded video wall function, no image splitter is required.
4K loop out port for daisy chain connection in cascade application.
Easy configuration via IR remote, PC tool, or WebGUI.
